●Working voltage: regulated 5V
●Working current: peak 1A
●Size: 272* 177* 2.4mm
●Weight: 252 grams
●1. Single crystal film is used as the
power generation material, and the
film aluminum plate high temperature
laminate process is used
●2.With voltage regulator
●3. The solar backplane is all aluminum,
which has good heat dissipation and
stable irradiation current for a long
●6W Solar Charger USE Tuankou
Camping Travel Charger Outdoor
Emergency Mountaineering and
Hiking Easy to store with voltage
stabilizer, which can charge mobile
●Suitable for bicycles, mobile
phones, mobile power supplies, 5V
water pump USB cameras, power
bank Bluetooth headsets,
Bluetooth speakers, outdoor
cameras, handheld GPS navigation
systems, MP3, MP4, game
consoles, lawn wall lights and
other 5V devices.
●Suitable for small fish pumps, small fans, small motors
and other small equipment
●Suitable for outdoor watch GPS earphone security camera
●Suitable for emergency use of all electronic products
Thanks for choosing Portable Solar Charger. We believe it will bring much convenience to your life.
The Solar Charger is lightweight and Durable. It can convert the solar energy into electric power
charge power banks and other electronic devices anywhere and anytime. The solar charger is ideal
for long-distance lravel, feld trips when there is no available electric power. When not sufficient
sunlight is available, it can be used togelher with power bank for power the electronics . This solar
charger is designed user-friendly. It makes full Use of exible solar cell which is small in size, light
in weight, flexible in feature, and can be easily integrated to the surface of all kinds of architectures,
tents and daily necessilies and devices . The solar charger can immediately produce low cost
●USB output: Supports other low-current devices, GPS devices. watches, small pumps,
security camera. etc. Support mobile phone and other electronic devices.
●Built-in regulator system making the output more stable.
●Low voltage output without safety risks.
●Works well with low-light sesilvity.
●Integraled high qualty lamination productlong lasting product comparison.
●Embossed sutace making the panel more durable. sylish and improving lght absorbanco by5%
●Best solar products with light weigh.potable and stable peromance.
Charging status Note
This device does not have an indicator light, charging refers to the indicator light of
the charging device.
Note: If the device indicalor light is not lit or the charging is slow, it means that the light is not Ideal,
please adjust the product angle or position.
It is not recommended to use solar power
in the following environments
a. Cloudy, rainy, snowy, smog weather
b. Fluorescent lamps
c. Inside the aircraft, inside the car
Charging Electronic Devices
the solar panel under direct sunlight, connect solar charger withthe electronic device through power
output cable, the charging signalwill be shown on your electronic device; or if the sunlight Is not
suficient, the solar charger can be connected with power bank for energy storage.
When the charger is connected
as instructed above, the electronic
device shows: “Charging is
temporary unavailable* or no sign
for charging. Please pull out the
output cable and reconnect, or
adjust the angle of the charger to
Is it harmful to use solar panel to charge mobile phone directly?
❹No,Build-in 5V regulator system making the output more stable.
Is this solar pannel waterproof?
❻Yes, this solar panel is waterproof.
Is the solar panel limit to the security inspection of subway and plane?
❻No, itcan be taken to the subway and plane.
Can2 solar panels be used in series, in the case of small current for one solar panel?
❻Yes, the solar panel Is equipped with a DC port, which can be connected with a DC cable.
1. Please avoid excessive light exposure for long time storage.
2. Avoid placing in the high temperature(>70″C),humidity and corrosive environments.
3. Do not reverse charging to the solar charger to avoid damage to the internal circuit.
4. When charging ,do not block any part of the solar panel.
5. The charging performance of this product depends on many factors, including solar
exposure angle, weather conditions, ambient temperature, etc.
6. It is recommended to use this product outdoors, and it is necessary to avoid blocking
the solar panels when using. otherwise it will greatly reduce the power generation and
affect the charging experience.
7. When the lighting conditions are not good, such as indoors, in the car, in the balcony,
cloudy, rainy, cloudy, smog, etc., the output current of this product is small or can not
work, can not charge the battery product.
8. Do not wipe or soak with water, chemicals and corrosive liquids. Immediately wipe the
product dry with a dry cloth when wet.
9. Do not open, alter, reassemble, drop, shake or bang the solar connector.
10. Do not connect USB out (+) and input(-) ends to short the circuit.
11. Do not discard the product in water or fire to avoid damage to charger circuit.
12. This product provides USB (Type A) output interface. please choose the appropriate
cable, or choose the corresponding accessories of this product.
